| Release: | 1975 |
|---|---|
| Record grading: NM used - excelent condition more info here | |
Description
Hi-Fi system amplifier Kenwood KA-6005, tuner Kenwood KA-6004 pro AM/FM and speakers KL-7090.
KA-6005
Specifications
Power output: 50 watts per channel into 8Ω (stereo)
Frequency response: 20Hz to 30kHz
Total harmonic distortion: 0.8%
Damping factor: 50
Input sensitivity: 2mV (MM), 150mV (line)
Signal to noise ratio: 60dB (MM), 70dB (line)
Output: 150mV (line), 30mV (DIN)
Semiconductors: 22 x transistors, 10 x diodes, 2 x thermistors
KT-6004
Specifications
Type: Mono/Stereo Tuner
Tuning Bands: FM, MW
Tuning Scale: Analogue
FM Tuning Range: 88 to 108 MHz
MW Tuning Range: 50 to 160 kHz
Sensitivity: 2.0uV (FM)
Signal to Noise Ratio: 60dB (FM), 45dB (MW)
Distortion: 0.7% (FM)
Selectivity: 45dB (FM), 25dB (MW)
Output: 1000mV (FM), 400mV (MW)
KL-7090
64cm high
5 way 6 speaker system,
Horn loaded and adjustable crossover,
8 ohms,
120 watts,
